In Stock Schneider ATS22D47Q soft starter-ATS22-control 220V-power 230V(11kW)/400...440V(22kW)

In Stock Schneider ATS22D47Q soft starter-ATS22-control 220V-power 230V(11kW)/400...440V(22kW)

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Main

Range of productAltistart 22

Product or component typeSoft starter

Product destinationAsynchronous motors

Product specific applicationPumps and fans

Component nameATS22

Network number of phases3 phases

[Us] rated supply voltage230...440 V - 15...10 %

motor power kW11 kW 230 V

22 kW 400 V

22 kW 440 V

Factory setting current42 A

power dissipation in W48 W for standard applications

Utilisation categoryAC-53A

Type of startStart with torque control (current limited to 3.5 In)

IcL starter rating47 A for connection in the motor supply line for standard applications

IP degree of protectionIP20

In Stock Schneider ATS22D47Q soft starter-ATS22-control 220V-power 230V(11kW)/400...440V(22kW)

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Complementary

Assembly styleWith heat sink

Function availableInternal bypass

Supply voltage limits195…484 V

supply frequency50...60 Hz - 10...10 %

Network frequency45...66 Hz

Device connectionTo the motor delta terminals

In the motor supply line

[Uc] control circuit voltage230 V - 15...10 % 50/60 Hz

Control circuit consumption20 W

Discrete output number2

discrete output typeRelay outputs R1 230 V running, alarm, trip, stopped, not stopped, starting, ready C/O

Relay outputs R2 230 V running, alarm, trip, stopped, not stopped, starting, ready C/O

minimum switching current100 mA at 12 V DC (relay outputs)

maximum switching current5 A 250 V AC resistive 1 relay outputs

5 A 30 V DC resistive 1 relay outputs

2 A 250 V AC inductive 0.4 20 ms relay outputs

2 A 30 V DC inductive 7 ms relay outputs

Discrete input number3

discrete input type(LI1, LI2, LI3) logic, 5 mA 4.3 kOhm

discrete input voltage24 V <= 30 V

discrete input logicPositive logic LI1, LI2, LI3 at State 0: < 5 V and <= 2 mA at State 1: > 11 V, >= 5 mA

output current0.4...1 Icl adjustable

PTC probe input750 Ohm

Communication port protocolModbus

connector type1 RJ45

Communication data linkSerial

Physical interfaceRS485 multidrop

Transmission rate4800, 9600 or 19200 bps

Installed device31

protection typePhase failure: line

Thermal protection: motor

Thermal protection: starter

MarkingCE

Type of coolingForced convection

Operating positionVertical +/- 10 degree

Height265 mm

Width130 mm

Depth169 mm

Net weight7 kg

Motor power range AC-37…11 kW at 200…240 V 3 phases

15…25 kW at 380…440 V 3 phases

Motor starter typeSoft starter

In Stock Schneider ATS22D47Q soft starter-ATS22-control 220V-power 230V(11kW)/400...440V(22kW)

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Environment

electromagnetic compatibilityConducted and radiated emissions level A conforming to IEC 60947-4-2

Damped oscillating waves level 3 conforming to IEC 61000-4-12

Electrostatic discharge level 3 conforming to IEC 61000-4-2

Immunity to electrical transients level 4 conforming to IEC 61000-4-4

Immunity to radiated radio-electrical interference level 3 conforming to IEC 61000-4-3

Voltage/current impulse level 3 conforming to IEC 61000-4-5

StandardsEN/IEC 60947-4-2

Product certificationsCCC

C-Tick

UL

GOST

CSA

vibration resistance1 gn (f= 13…200 Hz) conforming to EN/IEC 60068-2-6

1.5 mm (f= 2…13 Hz) conforming to EN/IEC 60068-2-6

shock resistance15 gn for 11 ms conforming to EN/IEC 60068-2-27

Noise level45 dB

pollution degreeLevel 2 conforming to IEC 60664-1

relative humidity0…95 % without condensation or dripping water conforming to EN/IEC 60068-2-3

ambient air temperature for operation-10…40 °C (without derating)

40…60 °C (with current derating 2.2 % per °C)

Ambient air temperature for storage-25…70 °C

operating altitude<= 1000 m without derating

> 1000...< 2000 m with current derating of 2.2 % per additional 100 m

Packing Units

Unit Type of Package 1PCE

Number of Units in Package 11

Package 1 Height26.924 cm

Package 1 Width22.098 cm

Package 1 Length33.274 cm

Package 1 Weight5.606 kg

Unit Type of Package 2P06

Number of Units in Package 210

Package 2 Height73.5 cm

Package 2 Width80 cm

Package 2 Length60 cm

Package 2 Weight69.76 kg

In Stock Schneider ATS22D47Q soft starter-ATS22-control 220V-power 230V(11kW)/400...440V(22kW)

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Similar model numbers:

ATS22C11Q

ATS22C14Q

ATS22C17Q

ATS22C21Q

ATS22C25Q

ATS22C32Q

ATS22C41Q

ATS22C48Q

ATS22C59Q

ATS22D17Q

ATS22D32Q

ATS22D47Q

ATS22D62Q

ATS22D75Q

ATS22D88Q
