Schneider ZB5AZ102C Single contact block with body fixing collar, Harmony XB5, plastic, screw clamp terminal, 1NC

Schneider ZB5AZ102C Single contact block with body fixing collar, Harmony XB5, plastic, screw clamp terminal, 1NC

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Main

Range of productHarmony XB5

Product or component typeComplete body/contact assembly

Device short nameZB5

Fixing collar materialPlastic

Sale per indivisible quantity1

Head typeStandard

Contacts type and composition1 NC

Contact operationSlow-break

Contact block typeSingle

connections - terminalsScrew clamp terminals, <= 2 x 1.5 mm² with cable end conforming to EN 60947-1

Screw clamp terminals, >= 1 x 0.22 mm² without cable end conforming to EN 60947-1

Complementary

CAD overall width30 mm

CAD overall height42 mm

CAD overall depth32 mm

Terminals description ISO n°1(11-12)NC

Product weight0.021 kg

Device compositionBody

Fixing collar

Contacts usageStandard contacts

positive openingWith conforming to EN/IEC 60947-5-1 appendix K

operating travel1.5 mm (NC changing electrical state)

4.3 mm (total travel)

operating force2 N NC changing electrical state

Mechanical durability10000000 cycles

tightening torque0.8…1.2 N.m conforming to EN 60947-1

shape of screw headCross compatible with Philips no 1 screwdriver

Cross compatible with pozidriv No 1 screwdriver

Slotted compatible with flat Ø 4 mm screwdriver

Slotted compatible with flat Ø 5.5 mm screwdriver

Contacts materialSilver alloy (Ag/Ni)

short-circuit protection10 A cartridge fuse type gG conforming to EN/IEC 60947-5-1

[Ith] conventional free air thermal current10 A conforming to EN/IEC 60947-5-1

[Ui] rated insulation voltage600 V (pollution degree 3) conforming to EN 60947-1

[Uimp] rated impulse withstand voltage6 kV conforming to EN 60947-1

[Ie] rated operational current3 A at 240 V, AC-15, A600 conforming to EN/IEC 60947-5-1

6 A at 120 V, AC-15, A600 conforming to EN/IEC 60947-5-1

0.1 A at 600 V, DC-13, Q600 conforming to EN/IEC 60947-5-1

0.27 A at 250 V, DC-13, Q600 conforming to EN/IEC 60947-5-1

0.55 A at 125 V, DC-13, Q600 conforming to EN/IEC 60947-5-1

1.2 A at 600 V, AC-15, A600 conforming to EN/IEC 60947-5-1

electrical durability1000000 cycles, AC-15, 2 A at 230 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to EN/IEC 60947-5-1 appendix C

1000000 cycles, AC-15, 3 A at 120 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to EN/IEC 60947-5-1 appendix C

1000000 cycles, AC-15, 4 A at 24 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to EN/IEC 60947-5-1 appendix C

1000000 cycles, DC-13, 0.2 A at 110 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to EN/IEC 60947-5-1 appendix C

1000000 cycles, DC-13, 0.5 A at 24 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to EN/IEC 60947-5-1 appendix C

electrical reliabilityΛ < 10exp(-6) at 5 V, 1 mA in clean environment conforming to EN/IEC 60947-5-4

Λ < 10exp(-8) at 17 V, 5 mA in clean environment conforming to EN/IEC 60947-5-4

Device presentationBasic sub-assemblies

Schneider ZB5AZ102C Single contact block with body fixing collar, Harmony XB5, plastic, screw clamp terminal, 1NC

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Environment

Protective treatmentTH

Ambient air temperature for storage-40…70 °C

Ambient air temperature for operation-40…70 °C

IP degree of protectionIP20 conforming to IEC 60529

StandardsUL 508

EN/IEC 60947-5-1

JIS C8201-5-1

EN/IEC 60947-1

CSA C22.2 No 14

EN/IEC 60947-5-4

JIS C8201-1

Product certificationsCSA

UL

GL

LROS (Lloyds register of shipping)

BV

DNV

vibration resistance5 gn (f= 2…500 Hz) conforming to IEC 60068-2-6

shock resistance30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27

50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27

Packing Units

Unit Type of Package 1PCE

Number of Units in Package 11

Package 1 Height4.500 cm

Package 1 Width3.400 cm

Package 1 Length5.400 cm

Package 1 Weight20.0 g

Unit Type of Package 2S03

Number of Units in Package 2300

Package 2 Height30.000 cm

Package 2 Width30.000 cm

Package 2 Length40.000 cm

Package 2 Weight6.512 kg

Unit Type of Package 3P06

Number of Units in Package 32400

Package 3 Height77.000 cm

Package 3 Width80.000 cm

Package 3 Length60.000 cm

Package 3 Weight64.604 kg
