Schneider ATV320U07M2C Variable speed drive, Altivar Machine ATV320, 0.75 kW, 200...240 V, 1 phase, compact

Schneider ATV320U07M2C Variable speed drive, Altivar Machine ATV320, 0.75 kW, 200...240 V, 1 phase, compact

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Main

range of productAltivar Machine ATV320

product or component typeVariable speed drive

product specific applicationComplex machines

variantStandard version

format of the driveCompact

mounting modeWall mount

communication port protocolModbus serial

CANopen

option cardCommunication module, CANopen

Communication module, EtherCAT

Communication module, Profibus DP V1

Communication module, PROFINET

Communication module, Ethernet Powerlink

Communication module, EtherNet/IP

Communication module, DeviceNet

[Us] rated supply voltage200...240 V - 15...10 %

nominal output current4.8 A

motor power kW0.75 kW for heavy duty

EMC filterClass C2 EMC filter integrated

IP degree of protectionIP20

Schneider ATV320U07M2C Variable speed drive, Altivar Machine ATV320, 0.75 kW, 200...240 V, 1 phase, compact

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Complementary

discrete input number7

discrete input typeSTO safe torque off, 24 V DC, impedance: 1.5 kOhm

DI1...DI6 logic inputs, 24 V DC (30 V)

DI5 programmable as pulse input: 0…30 kHz, 24 V DC (30 V)

discrete input logicPositive logic (source)

Negative logic (sink)

discrete output number3

discrete output typeOpen collector DQ+ 0…1 kHz 30 V DC 100 mA

Open collector DQ- 0…1 kHz 30 V DC 100 mA

analogue input number3

analogue input typeAI1 voltage: 0...10 V DC, impedance: 30 kOhm, resolution 10 bits

AI2 bipolar differential voltage: +/- 10 V DC, impedance: 30 kOhm, resolution 10 bits

AI3 current: 0...20 mA (or 4-20 mA, x-20 mA, 20-x mA or other patterns by configuration), impedance: 250 Ohm, resolution 10 bits

analogue output number1

analogue output typeSoftware-configurable current AQ1: 0...20 mA impedance 800 Ohm, resolution 10 bits

Software-configurable voltage AQ1: 0...10 V DC impedance 470 Ohm, resolution 10 bits

relay output typeConfigurable relay logic R1A 1 NO electrical durability 100000 cycles

Configurable relay logic R1B 1 NC electrical durability 100000 cycles

Configurable relay logic R1C

Configurable relay logic R2A 1 NO electrical durability 100000 cycles

Configurable relay logic R2C

maximum switching currentRelay output R1A, R1B, R1C on resistive load, cos phi = 1: 3 A at 250 V AC

Relay output R1A, R1B, R1C on resistive load, cos phi = 1: 3 A at 30 V DC

Relay output R1A, R1B, R1C, R2A, R2C on inductive load, cos phi = 0.4 and L/R = 7 ms: 2 A at 250 V AC

Relay output R1A, R1B, R1C, R2A, R2C on inductive load, cos phi = 0.4 and L/R = 7 ms: 2 A at 30 V DC

Relay output R2A, R2C on resistive load, cos phi = 1: 5 A at 250 V AC

Relay output R2A, R2C on resistive load, cos phi = 1: 5 A at 30 V DC

minimum switching currentRelay output R1A, R1B, R1C, R2A, R2C: 5 mA at 24 V DC

method of accessSlave CANopen

4 quadrant operation possibleTrue

asynchronous motor control profileVoltage/frequency ratio, 5 points

Flux vector control without sensor, standard

Voltage/frequency ratio - Energy Saving, quadratic U/f

Flux vector control without sensor - Energy Saving

Voltage/frequency ratio, 2 points

synchronous motor control profileVector control without sensor

maximum output frequency0.599 kHz

transient overtorque170…200 % of nominal motor torque

acceleration and deceleration rampsLinear

U

S

CUS

Ramp switching

Acceleration/deceleration ramp adaptation

Acceleration/deceleration automatic stop with DC injection

motor slip compensationAutomatic whatever the load

Adjustable 0...300 %

Not available in voltage/frequency ratio (2 or 5 points)

switching frequency2...16 kHz adjustable

4...16 kHz with derating factor

nominal switching frequency4 kHz

braking to standstillBy DC injection

brake chopper integratedTrue

line current4 A at 200 V (heavy duty)

8.4 A at 240 V (heavy duty)

maximum input current0.4166666666666667 A

maximum output voltage240 V

apparent power2.0 kVA at 240 V (heavy duty)

network frequency50...60 Hz

relative symmetric network frequency tolerance5 %

prospective line Isc1 kA

base load current at high overload33.0 A

power dissipation in WSelf-cooled: 45.0 W at 200 V, switching frequency 4 kHz

with safety function Safely Limited Speed (SLS)True

with safety function Safe brake management (SBC/SBT)False

with safety function Safe Operating Stop (SOS)False

with safety function Safe Position (SP)False

with safety function Safe programmable logicFalse

with safety function Safe Speed Monitor (SSM)False

with safety function Safe Stop 1 (SS1)True

with sft fct Safe Stop 2 (SS2)False

with safety function Safe torque off (STO)True

with safety function Safely Limited Position (SLP)False

with safety function Safe Direction (SDI)False

protection typeInput phase breaks: drive

Overcurrent between output phases and earth: drive

Overheating protection: drive

Short-circuit between motor phases: drive

Thermal protection: drive

width72.0 mm

Height143.0 mm

Depth138.0 mm

Net weight1.1 kg

Schneider ATV320U07M2C Variable speed drive, Altivar Machine ATV320, 0.75 kW, 200...240 V, 1 phase, compact

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Environment

operating positionVertical +/- 10 degree

product certificationsCE

ATEX

NOM

GOST

EAC

RCM

KC

MarkingCE

ATEX

UL

CSA

EAC

RCM

StandardsEN/IEC 61800-5-1

electromagnetic compatibilityElectrostatic discharge immunity test level 3 conforming to IEC 61000-4-2

Radiated radio-frequency electromagnetic field immunity test level 3 conforming to IEC 61000-4-3

Electrical fast transient/burst immunity test level 4 conforming to IEC 61000-4-4

1.2/50 µs - 8/20 µs surge immunity test level 3 conforming to IEC 61000-4-5

Conducted radio-frequency immunity test level 3 conforming to IEC 61000-4-6

Voltage dips and interruptions immunity test conforming to IEC 61000-4-11

environmental class (during operation)Class 3C3 according to IEC 60721-3-3

Class 3S2 according to IEC 60721-3-3

maximum acceleration under shock impact (during operation)150 m/s² at 11 ms

maximum acceleration under vibrational stress (during operation)10 m/s² at 13...200 Hz

maximum deflection under vibratory load (during operation)1.5 mm at 2...13 Hz

permitted relative humidity (during operation)Class 3K5 according to EN 60721-3

overvoltage categoryIII

regulation loopAdjustable PID regulator

speed accuracy+/- 10 % of nominal slip 0.2 Tn to Tn

pollution degree2

ambient air transport temperature-25…70 °C

ambient air temperature for operation-10…50 °C without derating

50…60 °C with derating factor

Ambient air temperature for storage-25…70 °C

Schneider ATV320U07M2C Variable speed drive, Altivar Machine ATV320, 0.75 kW, 200...240 V, 1 phase, compact

jeff@hkxytech.com   jeff@whxyauto.com   +86-15072331761

Packing Units

Unit Type of Package 1PCE

Number of Units in Package 11

Package 1 Height11.500 cm

Package 1 Width18.800 cm

Package 1 Length19.000 cm

Package 1 Weight1.330 kg

Unit Type of Package 2P06

Number of Units in Package 245

Package 2 Height75.000 cm

Package 2 Width60.000 cm

Package 2 Length80.000 cm

Package 2 Weight72.940 kg
